Thermo Scientific™
重力采样器
Thermo Scientific™ 重力采样器是一种经济实惠的简单采样方式，专为多流道分析器制采样品。
货号 19516
价格（CNY)/ Each申请报价
-
描述:
重力采样器
Thermo Scientific™ 重力采样器是一种经济实惠的简单采样方式，专为多流道分析器制采样品。Thermo Scientific 重力采样器是一种高性价比的采样方式，可为元素分析提供连续的样品流。
重力采样器备有各种尺寸，以适应不同的工艺流量，使用切刀和管口来控制样品流量。它配备一个检查点，方便维护和检查。特点
- 备有各种尺寸，可处理大多数的流速
- 紧凑型设计
- 切刀可通过检查点替换
- 提供表 D、E 和 ANSI 法兰
- 橡胶内衬
订购信息：
备有从 4 in.(100 mm) 至 36 in.(900 mm) 的管径供选用。
兼容：
MSA 多流 XRF 元素矿浆分析器 (PID-19502)
规格
描述重力采样器
材料Wear-resistant cutters in stainless steel; An inspection cover is fitted to the top of each sampler to allow for easy cutter cleaning
认证/合规Adelaide manufacturing site is quality assured to iso 9001:2000; Metalwork manufactured to Australian standard AS4041-2016 (or equivalent)
包括
- Lining: 6-mm (1/4”) rubber applied to BS 6374 Part 5:1995
- Flushing Tee: Flushing tee on pressure pipe and gravity sample outlet is lined with highest-grade wear-resistant, molded polyurethane
- External Finish: Epoxy paint meeting our highest internal standards
- Flange: Can be supplied to most common flange standards like: SAME/ANSI, SANS1123, DIN-EN 1092, and AS2129
- Fastener: 316 stainless steel
- Slurry Valves (optional): Diaphragm-type slurry valves can be supplied; Normal sizes are: 50 mm (2”) for the sample outlet shut-off valve, 25 mm (1”) for the wash valve
直径Avialable in 100 mm (4 in) NB to 900 mm (36 in) NB
Unit SizeEach
